Super Bronco™ 50K FAB XP Riding Lawn Mower
Item#:
13AQA1BLA66
price.from
$2,799.00
price.msrp
Super Bronco™ 50K FAB XP Riding Lawn Mower
Item#:
13AQA1BLA66
price.from
$2,799.00
price.msrp
Tackle tough jobs with the durability of the 50" fabricated steel deck on the Troy-Bilt® Super Bronco™ 50K FAB XP riding mower. A large Step-Thru™ frame is designed for easy on-and-off access and includes a rear hitch for quick attachment of tow-behind accessories, like dump carts, spreaders, or aerators (attachments sold separately). Hydrostatic transmission helps provide a smooth change of speed and direction and includes cruise control to help operate at a constant speed.
Documents and Guides
- Powerful 24 HP*/725cc twin-cylinder KOHLER engine designed to deliver\s quiet, balanced performance
- 50" fabricated steel side discharge deck helps minimize mowing time in large areas up to 2 acres and has four anti-scalp deck wheels and a nose roller help prevent turf damage.
- Hydrostatic transmission has foot-pedal control for a smooth change of speed and direction and includes cruise control to help mow at a constant speed
- Electric PTO quickly and easily engages cutting blades
- Lawn Tractor
You May Also Like
![CHAINS 20"X8"](https://www.troybilt.com/dw/image/v2/BCSH_PRD/on/demandware.static/-/Sites-mtd-master-catalog/default/dw960d4983/products/Attachments_Accessories/490-241-0023.jpg?sw=280&sh=280&sm=fit "CHAINS 20"X8"")
![42" 3-Stage Snow Blower Attachment](https://www.troybilt.com/dw/image/v2/BCSH_PRD/on/demandware.static/-/Sites-mtd-master-catalog/default/dw4a88273b/products/19B40024OEM "42" 3-Stage Snow Blower Attachment")
Super Bronco™ 50K FAB XP Riding Lawn Mower Features
XP Series™
Extra power, durability and comfort features in the Troy-Bilt XP line of mowers
Hydrostatic
Hydrostatic transmission with foot pedal control for smooth, clutchless operation.
Durability
Cast iron front pivot bar provides added durability and rugged performance.
Ride With Comfort
Ride with more comfort and support with the adjustable high-back seat.
Maneuverability
Save time with enhanced maneuverability around landscape borders and obstacles thanks to a 16" turn radius
Easy Access
Rugged StepThru™ frame design makes it easy to get on and off your riding mower.
Confidence
3-year limited warranty for extended peace of mind.
Pride
Headquartered in Valley City, OH, select Troy-Bilt items are designed, built and tested right here in the U.S.— with U.S. and global parts — from Ohio and Mississippi to Tennessee and Arizona.
Easier Clean-Up
Make yard clean up easier by using an available rear bagger to collect grass clippings and leaves for composting or disposal.
50" Cutting Deck
Large 50" deck mows large areas faster and more efficiently while delivering a clean, even cut.
Versatile Performance
Convenient rear hitch makes attaching available tow-behind attachments, like dump carts, spreaders or aereators, easy and quick.
Deck Wash
Attach a standard garden hose to the deck wash port to quickly clean underside of deck and prevent buildup of clippings
Specs & Maintenance
Engine
- Engine Brand Kohler®
- Engine Model 7000 Series
- Engine Model Number KT735
- Engine Displacement 725cc
- Engine Output 24HP
- Starter Type Electric
- Fuel Tank Capacity 3.0 gal. US (11.36 L)
- Cylinders Twin
- Engine Start Ignition Key
- Engine Oil Capacity 2.0 qt. US (1.89 L)
- Lubrication Fully pressurized
- Charging System 12 amp regulated
- Fuel Gauge No
- Governor Mechanical
- Choke Separate Choke
- Air Filter Dual element
- Oil Filter Yes
- Fuel Delivery Carburetor
Battery
- Battery 210 CCA
- Battery Type AGM (Absorbent Glass Mat)
- Battery Voltage 12V
Drive System
- Transmission Tuff Torq® K46
- Forward Speed 5.5 MPH / 8.6 km/h
- Reverse Speed 2.5 MPH / 4 km/h
- Rear Axle 3/4"
- Drive System Hydrostatic
- Transmission Control Foot Pedal
- Transmission Housing Aluminum
- Rear Differential Lock No
Cutting Deck
- Deck Cutting Width 50 in
- Deck Wash Yes
- Deck Material 11-gauge steel
- Deck Engagement (PTO) Electric
- Deck Construction Fabricated
- Blade(s) Three
- Deck Lift Hand lever
- Cutting Height Range 1.5” - 3.75”
- Anti-Scalping Five gauge wheels
- Deck Positions 12
Chassis
- Frame Robotically welded
- Turning Radius 16"
- Bumper No
- Rear Tow Hitch Yes
- Corrosion Protection Yes
- Front Pivot Bar Cast iron
Controls
- Cruise Control Yes
- Brakes Disc
Comfort
- Seat Type High-back
- Armrests No
- Seat Adjustment Lever
- Floor Mats Rubber
Wheels
- Bearing Type Poly Bushing
- Rear Tires 20"x 8"-8"
- Front Tires 15"x 6"-6"
- Tire Tread Turf Saver
Additional Specifications
- Mulch Kit Available Separately
- Headlight(s) Standard
- Cup Holder Yes
- Operator Presence System Yes
- Model Number 13AQA1BLA66
Warranty
- Residential Warranty 3-year limited residential
- Frame Warranty 3-year limited
- Front Axle Warranty 3-year limited
- Deck Shell Warranty 3-year limited
- Commercial Warranty No
Disclaimers
- Specifications Specifications subject to change without notice and without incurring obligation. Products depicted on website and other advertisements are for demonstration purposes only. Actual products offered for sale may vary in design, required attachments, safety features and non-functional appearance from. See other general disclaimers at the bottom of our website.
- Horsepower *As rated by engine manufacturer
Model | Manual | Form Number | |
|---|---|---|---|
| 13AQA1BLA66 | MAN:OPER:DIG:TRILING:NX15 | ||
| MAN:OPER:DIG:TRILING:NX15 | 769-25738B | Download | |
| MAN:OPER:DIG:TRILING:NX15 | 769-25738C | Download | |
| MAN:OPER:DIG:TRILING:NX15 | 769-25738D | Download | |
| MAN:OPER:DIG:TRILING:NX15 | 769-25738E | Download | |
| MAN:OPER:DIG:TRILING:NX15 | 769-26860 | Download | |
| MAN:OPER:DIG:TRILING:NX15 | 769-26989 | Download | |
| SHEET:SUP:BILING:EPA:EVP:20-21 | 769-25879 | Download | |
| SHEET:SUP:BILING:EPA:EVP:21-22 | 769-26272 | Download | |
| SHEET:SUP:BILING:EPA:EVP:22-23 | 769-26607 | Download | |
| SHEET:SUP:Warranty_Addendum_In | 769-26830 | Download | |
| SHEET:SUPP:WARR/PARTS:TRI:TB X | 769-26248 | Download | |
| SHEET:SUPP:WARR/PARTS:TRI:TB X | 769-26637 | Download | |
| SHEET:SUPP:WARR/PARTS:TRI:TB X | 769-26637A | Download | |
| SHEET:SUPP:WARR/PARTS:TRI:TB X | 769-26842 | Download | |
| SHEET:SUPP:WARR/PARTS:TRI:TB X | 769-26891 | Download | |
| SHEET:SUPP:WARR/PARTS:TRI:TB X | 769-26891A | Download |
