Mustang Z54 XP Zero-Turn Mower
Item#:
17ASFAC3A66
Financing Available
price.from
$4,599.00
price.msrp
Financing Available
Mustang Z54 XP Zero-Turn Mower
Item#:
17ASFAC3A66
price.from
$4,599.00
price.msrp
Tackle tough jobs and heavy mowing conditions with the durability of the 54" fabricated steel deck on the Troy-Bilt® Mustang™ Z54 FAB XP zero-turn rider. Two front deck wheels and a nose roller help provide a smooth ride. The dual hydrostatic transmissions are designed to quickly turn at the end of a row and mow around trees and landscape beds. The rugged steel frame is engineered to absorb impact, provide stability, and is covered by a limited lifetime warranty.
Documents and Guides
- Powerful 24 HP*/725cc KOHLER® PRO twin-cylinder engine designed to deliver quiet, balanced performance
- 54" fabricated steel cutting deck is designed for durable performance in heavy mowing conditions and has 2 anti-scalp deck wheels, plus nose roller to help prevent turf damage
- Full-length, fully welded, 2 " tubular steel frame is designed to absorb impact, provide stability and is covered by a limited lifetime warranty
- Dual hydrostatic transmissions with lap bar control deliver true zero-turn performance and are designed to help quickly cut and maneuver around obstacles while mowing.
- Adjustable, 18" high-back seat with arm rests and foam-grip steering controls help provide a comfortable ride
- Zero-Turn Mower
You May Also Like
Mustang Z54 XP Zero-Turn Mower Features
Heavy-Duty Frame
Heavy-duty 2" tubular frame absorbs impact, provides maximum stability and is covered by a limited lifetime warranty.
Increased Comfort
Ride in more comfort and with reduced vibration thanks to the high-back seat and foam grip steering controls.
Easy Blade Engagement
Quickly engage the cutting deck with conveniently located, console-mounted knob.
Safety First
Lap bar controls have an integrated parking brake to safely and quickly stop the mower.
Quickly Adjust Cutting Height
8-position height adjustment on the fender makes it easy to change cutting heights from 1.5" - 4"
Reduced Turf Damage
Anti-scalp deck wheels and Turf Master tires keep your lawn looking beautiful.
Easier Clean-Up
Make yard clean up easier by using an available rear bagger to collect grass clippings and leaves for composting or disposal.
Versatile Performance
Convenient rear hitch makes attaching available tow-behind attachments, like dump carts, spreaders or aereators, easy and quick.
XP Series™
Extra power, durability and comfort features in the Troy-Bilt XP line of mowers
Enhanced Durability
Fabricated 11-gauge steel cutting deck provides enhanced durability.
Pride
Headquartered in Valley City, OH, select Troy-Bilt items are designed, built and tested right here in the U.S.— with U.S. and global parts — from Ohio and Mississippi to Tennessee and Arizona.
Confidence
Limited lifetime warranty on full-length tubular frame and a 3-year limited on other components.
Specs & Maintenance
Engine
- Engine Brand Kohler®
- Engine Model 7000 series PRO
- Engine Model Number KT735
- Engine Displacement 725cc
- Engine Output 24HP
- Starter Type Electric
- Fuel Tank Capacity 3.5 gal. US (13.25 L)
- Cylinders Twin
- Engine Start Ignition Key
- Engine Oil Capacity 2.0 qt. US (1.89 L)
- Lubrication Fully pressurized
- Charging System 12 amp regulated
- Fuel Gauge No
- Governor Mechanical
- Choke Choke-a-matic
- Air Filter Dual element
- Oil Filter Yes
- Fuel Delivery Carburetor
Battery
- Battery 210 CCA
- Battery Type AGM (Absorbed Glass-Mat)
- Battery Voltage 12V
Drive System
- Transmission Tuff Torq TZ 350
- Forward Speed 7 MPH / 11.3 Km/H
- Reverse Speed 3.5 MPH / 5.6 Km/H
- Drive System Hydrostatic
- Transmission Housing Cast aluminum
Cutting Deck
- Deck Cutting Width 54 in
- Deck Wash No
- Deck Material 11-gauge steel
- Deck Engagement (PTO) Electric
- Deck Construction Reinforced Flat Top
- Blade(s) 3
- Deck Lift Foot pedal
- Cutting Height Range 1'' - 4.5''
- Anti-Scalping 3 gauge wheels
- Deck Positions 8
Chassis
- Frame 2'' x 2'' tubular steel
- Turning Radius 0°
- ROPS No
- Rear Tow Hitch Yes
- Corrosion Protection Yes
Controls
- Cruise Control No
- Brakes Disc
- Steering Control Lap Bars
Comfort
- Seat Type 18" high back
- Armrests Yes
- Seat Adjustment Lever
Wheels
- Rear Tires 20''x 12''- 8''
- Front Tires 13"x 6.5"-6"
- Tire Tread Turf Master / Multi Trac
Additional Specifications
- Hour Meter Available separately
- Mulch Kit Available separately
- Headlight(s) No
- Cup Holder Yes
- Operator Presence System Yes
- Parking Brake Lap Bar Integrated
- Model Number 17ASFAC3A66
Warranty
- Residential Warranty 3-year limited residential
- Frame Warranty Lifetime Limited
- Deck Shell Warranty Lifetime limited
- Commercial Warranty No
Disclaimers
- Specifications Specifications subject to change without notice and without incurring obligation. Products depicted on website and other advertisements are for demonstration purposes only. Actual products offered for sale may vary in design, required attachments, safety features and non-functional appearance from. See other general disclaimers at the bottom of our website.
- Horsepower *As rated by engine manufacturer
Model | Manual | Form Number | |
|---|---|---|---|
| 17ASFAC3A66 | MANL:OPER:TRILING:RZ19:DIGEST | ||
| MANL:OPER:TRILING:RZ19:DIGEST | 769-25609B | Download | |
| MANL:OPER:TRILING:RZ19:DIGEST | 769-25609C | Download | |
| MANL:OPER:TRILING:RZ19:DIGEST | 769-26504 | Download | |
| MANL:OPER:TRILING:RZ19:DIGEST | 769-26504A | Download | |
| MANL:OPER:TRILING:RZ19:DIGEST | 769-26861 | Download | |
| SHEET:SUP:BILING:EPA:EVP:20-21 | 769-25879 | Download | |
| SHEET:SUP:BILING:EPA:EVP:21-22 | 769-26272 | Download | |
| SHEET:SUP:BILING:EPA:EVP:22-23 | 769-26607 | Download | |
| SHEET:SUP:Warranty_Addendum_In | 769-26830 | Download | |
| SHEET:SUPP:WARR/PARTS:TB RZ19 | 769-26345 | Download | |
| SHEET:SUPP:WARR/PARTS:TB RZ19 | 769-26642 | Download | |
| SHEET:SUPP:WARR/PARTS:TB RZ19 | 769-26642A | Download | |
| SHEET:SUPP:WARR/PARTS:TB RZ19 | 769-26642B | Download | |
| SHEET:SUPP:WARR/PARTS:TB RZ19 | 769-26890 | Download |
